Spray Drying Machine

You are here:--Spray Drying Machine

Fruit Powder Spray Drying Machine Introduction

As the name suggests, the spray drying machine is special equipment that adopts spray drying to produce dry powder from a liquid or slurry by rapid drying with a hot gas. Spray drying is the most economical method of evaporation to produce dried powders. In the market, powder spray drying machine is popular for powder drying processes. Compared to other types of drying machine, Azeus fruit powder spray dryer machine can dry materials quickly with high quality, low water activity for easier transportation and storage. Moreover, it can be widely used in the chemical industry, plastic resins, food industry, ceramics and so on.

Fruit Powder Spray Drying Machine Introduction

Applications of Spray Drying Machine

1. In the food industry: fruit powder, milk powder, coffee, tea, eggs, cereal, spices, flavorings, etc.
2. Pharmaceutical: antibiotics, medical ingredients, additives, and so on.
3. Industrial: paint pigments, ceramic materials, catalyst supports.
Application of Spray Drying Machine

Final Fruit Powder Products Made by Spray Dryer Machine

Fruit Powder Products Made by Spray Dryer Machine

Working Principle of Spray Drying Machine

After filtering and heating, the air is blown into air distributor that is on the top of the drying machine. The hot air in spiral form equably enters the drying chamber. At the same time, liquid raw materials pass through the high-speed centrifugal sprayer on the top of the machine, moreover, they are rotated and sprayed into the extreme slim mist liquid beads. So the evenly and swirly distributed hot air completely contact with raw materials. In several seconds, the materials will be dried into a powder and discharged continuously from the bottom of the drying tower
Working Principle of Spray Drying Machine

Main Parts of Powder Spray Drying MachineSpotlight of Fruit Powder Dryer Machine

1. Drying speed is fast: due to the enlarged surface of the material, 95%-98% of water can be evaporated instantly in several seconds. It is more suitable for drying thermal sensitive materials to maintain color, smell, and taste of raw materials.
2. High-quality final products: finished products featured with high-purity, good uniformity, good flow capability, and solubility advantages.
3. Simple and stable operation, convenient to control and debug, easy to achieve automatic operation.
4. It is easy to replace the main parts and adjust the material staying time. Besides fruit powder, it is suitable for the chemical industry, plastic resins, food industry, ceramics and so on.
5. Suitable for large scale food powder drying production. For small scale food drying, you’d better choose small hot air circulation drying oven.

Main Parts of Powder Drying Machine

1.Feeding system

♦ Feeding pump is to keep feeding smoothly
♦ The atomizer is driven by motor directly with variable frequency control and imported bearings. The atomizer can make slurry vaporific continuously and evenly and enlarges the superficial area for heat exchange with hot air.
♦ The induced draft fan can help remove water steam out.

2.Air processing system

It adopts primary filter and medium efficiency filter to ensure that the air used for drying is the clean and filtered air.

3. Drying system

Drying chamber consists of hot air volume, hot air distributor, air disperser, inner tower body, outer tower body, tower frame, discharge pipe, thermal insulation material, observing and clean door, lamp hole and etc..

4. Material collecting system

The first cyclone separator can collect 80% powder and the other 19.8% can be collected by the second cyclone separator. The total collecting rate can be up to 99%.

5. Electric controller

Start the motor stable.

Video of ZLPG-200 Spray Drying Machine

Note: If you need a small sized spray dryer for laboratory, we can supply you too.

Technical Parameters of Powder Spray Drying Machine

Model ZLPG-5 ZLPG-10 ZLPG-25 ZLPG-50 ZLPG-80 ZLPG-100 ZLPG-150 ZLPG-200 ZLPG-300
Evaporated amount

of moisture(kg/h)

5 10 25 50 80 100 150 200 300
Treated amount of

raw material liquid(kg/h)

6-7 12-14 25-34 50-68 80-108 100-135 150-203 200-270 300-406
Output of finished

product(kg/h)

1-2 2-4 4.8-7.2 9.2-14 14.8-22.4 18.4-28 28-42 36.8-58.4 55-85
Solid content of

damp raw material(%)

18-25
Moisture content of

the final product (%)

3-5
Electric power(kW) 36 45 63 99 132 153 204 246 330
Heating source Steam and electricity
Product collection

way & efficiency

Two-grade cyclone duster or one-grade cyclone duster and one-grade
Automatic control

instrument

Indicator of the temperature of hot air and humidity of air exhaust
The temperature of the air in(℃) 150-200
The temperature of air out(℃) 80-100
L 5000 5500 7000 8000 9800 11000 12200 14100 15000
Dimension(mm) W 3000 3500 4000 5000 5700 6200 7000 7800 9000
H 45000 4600 5200 6500 7600 8100 9000 9850 11100
